Motor qty.
|
4
|
|
Alignment method
|
Cladding alignment, Core alignment
|
|
Applicable fibers |
Any common optical fibers, rubber-insulated fibers and jumpers that meet require ments of ITU-TG.651~653, ITU-TG.655 and
ITU-TG.657. |
|
Optical fiber diameter
|
Cladding: 80～150μm, coating layer: 0.1～3mm
|
|
Cleave length
|
5～16mm (coated optical fiber diameter ≤250μm);
10mm (coated optical fiber diameter: 0.25~3mm) |
|
Splice loss (typical)
|
0.03dB (SMF); 0.01dB (MMF);
0.05dB (DSF); 0.04dB (NZDSF) |
|
Return loss
|
Better than 60dB
|
|
Splicing time (typical)
|
7s (Fast mode)
|
|
Heating time (typical)
|
18s (60mm protection sleeve)
|
|
Tension
|
1.96～2.25N
|
|
Protection sleeve
|
60mm, 40mm and a series of protection sleeves
|
|
Graphical display
|
High-performance 4.3 inch LCD
|
|
Magnification time
|
320 times/88 times, 700 times
|
|
Fusion records
|
10000 groups
|
|
Battery capacity
|
11.1V, 6800mAh
|
|
Battery operating life
|
Cycle charging: 300～500 counts, can be replaced by customers
|
|
Electrode operating life
|
Typical: 4000 counts, can be replaced by customers
|
|
Construction lighting
|
Built-in lights with high-brightness and wide lighting area
|
|
Working environment
|
Temp:-10～50℃; Hum: 0～95%RH, height above sea level: 0～6000m
|
|
Operation interfaces
|
GUI
|
|
External power
|
AC: 100～240V, 60Hz, 0～1.5A; DC: 10～15V
|
|
Port
|
USB / SD
|
|
Dimensions
|
120mm (W)×130mm (H)×154mm (D) (without rubber anti-vibration pad)
|
|
Weight
|
1.7kg (no battery), 2.0kg (with battery)
|
