GPON OLT(UT-GP8016,16 PON PORT)

GPON OLT 16PON(UT-GP8016) is a small-capacity cassette GPON OLT, meeting the requirements of ITU-T G.984/G.988 and relative standards of China Telecom/Unicom GPON, with super GPON access capacity, carrier-class reliability and the complete security function. It can satisfy long-distance optical fiber access requirement on account of its excellent management, maintenance and monitoring capability, abundant service features and flexible network mode. GPON OLT 16PON can be used with network management system so as to provide users with the comprehensive access and perfect solution.
UT-GP8016 provides 16 * GPON port for downlink, 4 *GE combo port and 2* 10G SFP+ port for uplink. The height is only 1U for easy installation and space saving. It is suitable for Broadcast three in one, video surveillance network, enterprise LAN, Internet of Things, etc.

Main Features

  •  Complies with ITU.G.984.x, provides comprehensive GPON network compatibility
  •  Downstream rates of up to 2.488Gbps and upstream rates up to 1.244Gbps
  •  Fiber access and gigabit port provide incredibly fast transfer speeds
  •  Supports OMCI remote management
CONTACT +

Parameter

Model No. UT-GP8016
Interface 16*PON port;
4 *1.25G SFP and 4*GE COMBO port,
2 *10G SFP+ port for uplink
Chipset BCM68622(Broadcom);
BCM56452(Broadcom)
Data Rates & Wavelength Upstream:1.244Gbps, 1310nm
Downstream: 2.488Gbps, 1490nm
Distance & Capacity 0~ 20Km;1:128(max)
External Power Supply AC: input 100~240V 50/60Hz;
DC: input 36V~75V;
Power Consumption ≤110W
Dimensions (Length * Width * Height) 440mm×44mm×380mm
Weight (Full-Loaded) ≤8kg
Working temperature -10°C~55°C
Storage temperature: -40°C~70°C
Relative humidity: 10%~90%, non-condensing
