UT-King's Unbalance Cassette Card Inserting Type 1x9 Uneven PLC Splitter Optical fiber With FC/APC Connector is a component that splits the optical light power from one route into different routes. Molex PLC Splitter offers premium factory controlled optical performance on a variety of connectors that enable fast, economical installation.
|
Parameter
|
Specification
|
||||||||
|
Operating Wavelength (nm)
|
1260 ~ 1650
|
||||||||
|
Type
|
1x4
|
1x8
|
1x16
|
2x4
|
2x8
|
2x16
|
1x32
|
2x32
|
1x64
|
|
Insertion Loss (dB) Max. *
|
<7.3
|
<10.4
|
<13.5
|
<7.6
|
<11.2
|
<14.5
|
<16.2
|
<18.2
|
<20.5
|
|
Uniformity (dB) Max.*
|
<0.8
|
<1.0
|
<1.5
|
<1.0
|
<1.5
|
<2.0
|
<2.0
|
<2.5
|
<2.5
|
|
PDL(dB)Max.*
|
<0.2
|
<0.2
|
<0.3
|
<0.3
|
<0.3
|
<0.4
|
<0.3
|
<0.4
|
<0.3
|
|
Directivity (dB) Min *
|
55
|
||||||||
|
Return Loss (dB) Min *
|
55(50)
|
||||||||
|
Operating Temperature (°C)
|
-5~ +75
|
||||||||
|
Storage Temperature (°C)
|
-40 ~ +85
|
||||||||
|
Fiber length
|
1m or custom length
|
||||||||
|
Fiber Type
|
Corning SMF-28e fiber
|
||||||||
|
Connector Type
|
Custom specified
|
||||||||
|
Power Handling (mW)
|
300
|
||||||||
